Screw fligh

Material: excellent low carbon steel
Manufacturing mothld; cold rolled
Application:
Used for screw conveyor, Mixture engineering machine, combine Harvest machine
Feather: 1.Continous length (endless), cut to any length design;
2.Smooth finished surface, uniform shape, high precision;
3.Good tensile strength and wear resistance.

Standard Type

Out. Dia.
(mm)

Inner Dia.
(mm)

Pitch
(mm)

Thickness of plate

Standard
Length (m)

¡é 100X ¡é 28 X100

¡é 100

¡é 28

100

3.5

2

¡é 125X ¡é 32 X125

¡é 125

¡é 32

125

3.5

2

¡é 160X ¡é 42 X160

¡é 160

¡é 42

120

3.5

2

¡é 160X ¡é 42 X160

¡é 160

¡é 42

160

3.5

2

¡é 200X ¡é 48 X160

¡é 200

¡é 48

160

3.5

2

¡é 200X ¡é 48 X200

¡é 200

¡é 48

200

5

2

¡é 250X ¡é 60 X200

¡é 250

¡é 60

200

5

2

¡é 250X ¡é 60 X250

¡é 250

¡é 60

250

5

2

¡é 320X ¡é 76 X250

¡é 320

¡é 76

250

5

2

¡é 320X ¡é 76X320

¡é 320

¡é 76

320

5

2

¡é 400X ¡é 108 X400

¡é 400

¡é 108

400

5

2

Custom: Non-standard flights can be custom fabricated to your specifications. Please send print or sample for fabrication of screw flight.
